O-Rings For Flare-O Tube Ends

/resources/o-ring-information/o-rings-for-flare-o-tube-ends    O-Rings For Flare-O Tube Ends




















TUBE

SIZE

STANDARD

A-W

PART #





ITEM #





F4003-

OPTIONAL

COMPOUNDS







I.D.





W

CH

(BUNA-N)

F4003

CH

(HI-TEMP)(1)

F4002-

HK

(VITON)

F4004-

CA

(EPM/EPDM)

F4006-

-4

F4003-4

0003

0200

0003

0003

.176 ±.005

.040 ±.003

-5

F4003-5

0004

0300

0004

0004

.228 ±.005

.040 ±.003

-6

F4003-6

0005

0400

0005

0005

.295 ±.005

.039 ±.003

-8

F4003-8

0006

0500

0006

0006

.395 ±.005

.040 ±.003

-10

F4003-10

0007

0600

0007

0007

.492 ±.007

.039 ±.003

-12

F4003-12

0008

0700

0008

0008

.614 ±.009

.070 ±.003

-14

F4003-14

0009

0800

0009

0009

.739 ±.009

.070 ±.003

-16

F4003-16

0010

0900

0010

0010

.864 ±.009

.070 ±.003

-20

F4003-20

0011

1000

0011

0011

1.114 ±.010

.070 ±.003

-24

F4003-24

0012

1100

0012

0012

1.364 ±.013

.070 ±.003

-32

F4003-32

0013

1200

0013

0013

1.862 ±.015

.103 ±.003

SAE Type CH was SAE Type 1 Type CA was SAE Type 2 and Type HK was SAE Type 3.



Specification

SAE/ASTM

Type CH

SAE/ASTM

Type CA

SAE/ASTM

Type HK

Usage

Nitrile Elastomer, 90 Durometer Hardness,  for petroleum based fluids

EPDM Elastomer, 80 Durometer Hardness, for water based hydraulic or nonpetroleum based  fluids

Fluorocarbon Elastomer, 90 Durometer Hardness, for petroleum or nonpetroleum based fluids

General

Service

High pressure applications of pneumatics, water based hydraulic fluids, lubricating oils, hydraulic oils, and gasoline

High pressure applications of nonflammable hydraulic fluids of phosphate ester base type

High pressure, high temperature applications of pneumatic, water based hydraulic fluids, lubricating oils, hydraulic oils, and fuels

Temperature

-35°C to 125°C (-30°F to 250°F)

-40°C to 125°C (-40°F to 250°F)

-25°C to 205°C (-15°F to 400°F)

Shore Hardness

90 pts ±5 pts

80 pts ±5 pts

90 pts ±5 pts

Elongation

100% min

150% min

100% min

Tensile

10 MPa min

10 MPa min

10 MPa min

Compound

Nitrile (Buna-N) to ASTM D 2000 or SAE J200 M4CH910B14E015E35Z1

Z1 = TR 10 temperature –21° C or lower.  Alternate Low Temperature Product Test, 5 hours at –30° C, rings compressed 25% of ID, no cracks.

EPDM to ASTM D 2000 or SAE J200 M7CA810A25B35F17

M7HK910A1-11B38EF31E088Z1

Z1 = TR 10 temperature –15°C or lower (similar to MIL-R 83248 Type 1, Class 2)









Lubrication

When assembling Type CH O-Rings with O-Ring style fittings, the O-Ring shall be coated with the fluid used or petrolatum before assembly to ease installation.

When assembling Type CA O-Rings with O-Ring style fittings, lubricate the O-Ring with the fluid used in the system.  Do not use a petroleum-based lubricant.

When assembling Type HK O-Rings with O-Ring style fittings, the O-Ring shall be coated with the fluid used or petrolatum before assembly to ease installation.





1.Type CH(HI-TEMP) Air-Way part #F4002, 90 Durometer Nitrile Compound,  temperature range –32°C to 135°C(-25°F to 275°F). Approved compounds National O-Ring Compound C67-90, Parker Seal Groove Compound N1059-90.
